Output Voltage:

0.35mVrms (1kHz 35.4mm/sec., at 45°peak)

Coil Impedance:

6.0 ohms (1kHz)

Appropriate Stylus Force:

2.0grams ±0.2 grams

Frequency Response:

10Hz ～ 45kHz

Channel Separation:

over 27dB (1kHz)

Channel Balance:

within 1.0dB (1kHz)

Stylus Chip:

Oval-shaped solid Diamond

Cantilever:

Double layered duralumin pipe.

Weight:

10 grams

Compliance:

7 x 10^-6cm/dyne
