POWER SUPPLY

Nominal line voltage: 117 or 234 V (switchable)

Fuse 2.5A for 110V and 220V

Input voltage range: +/- 10 %

ANALOG INPUTS

4 x RCA analog input (Left & Right)

DIGITAL INPUTS

1 x Digital S/PDIF coaxial RCA 75 Ohms or Toslink Optical

1 x Digital S/PDIF coaxial RCA 75

1 x USB AUDIO (up to 96 kHz /24 bits)

REAR PANEL ONNECTORS AND CONTROLS

1 x analog output RCA connector Left & Right

1 x USB Audio connector

ON/OFF power switch key

Voltage input selector

RS232 Command connector

INPUT

Input impedance: 50 kOhms

Nominal input level: 2.25 V RMS

Maximum input level (unbalanced): 3.6 V RMS

OUTPUT

Output impedance: 75 Ohms

Maximum output level (unbalanced): 3.6 V RMS

FREQUENCYRESPONSE These values for any level to maximum output level

+/- 0.1 dB, 10 - 20 kHz

+/- 1.5 dB, 10 - 100 kHz

+/- 3 dB, 10 - 200 kHz

DISTORTION With 1 V RMS output level, 80 KHz measurement bandwidth, 600 Ohms termination impedance

THD unbalanced in to unbalanced out < 0.005% (-90 dB) flat with frequency

IMD unbalanced in to unbalanced out < 0.002% (-80 dB)

NOISE

Signal-to noise ratio: > 120 dB at 0 dBFS

OPERATING TEMPERATURE

Room temperature: -30 to +40 degrees Celsius (-22 to +104 degrees Fahrenheit)

Internal temperature: +45 to +65 degrees Celsius (+113 to +149 degrees Fahrenheit)

DIMENSIONS AND WEIGHT

44 W x 43 D x 13 H (cm)

Weight: 12 kg
