POWER SUPPLY
|
Nominal Line Voltage 117 ; 234V
|
|
AC line range: 10%
|
|
Fuse 16A for 115 and 230V
|
|
10 toroidal transformers
|
|
Separated ground and earth signal
|
|
Connection between earth and ground to cancel all ground loops
|
|
Rated power consumption: IEC 60065, 1/8 Output Power at 8 Ω: 210 W
|
|
Max power consumption: IEC 60065 at 8 Ω /1% THD: 550 W
|
|
FRONT PANEL
|
2 control keys
|
|
Red led display for Over-heating, DC offset or HF protection and Overload
|
|
Green led display for Power ON, operating mode
|
|
Yellow led display for AC line connection
|
|
Slew rate: Unloaded,18V/μS
|
|
REAR PANEL
|
Power cord: universal socket 3 lugs
|
|
Main fuse (16 A slow-blow)
|
|
Green-yellow AC earth binding post
|
|
Output speaker 1 x 5 ways post
|
|
Analog Input connector RCA
|
|
Input connector XLR for analog balanced input
|
|
Digital input and output RCA connector
|
|
Output speaker 1 x coaxial connector
|
|
INPUT
|
Max level before clipping:
|
|
Analog input: 1Vrms
|
|
Digital input: - 6 dBFS
|
|
OUTPUT
|
Max level before clipping: 1 % THD, unloaded: 153 Vpp
|
|
PERFORMANCE
|
|
Output power:
|
Power RMS (Goldmund FPP Standard): 350 Wrms on 8 Ω.
|
|
Maximum power (IEC60065): 335 Wrms on 8 Ω / 1%THD
|
|
Bandwidth:
|
20Hz - 20KHz: +/-0,03dB, unloaded
|
|
+/- 3dB: 0Hz to 100 kHz (limited by protection circuitry), unloaded
|
|
Distortion:
|
IMD (SMPTE), unloaded: < 0.03 %
|
|
THD+N, unloaded: < 0.06 % from 20 Hz to 20 kHz at 20 Vrms output
|
|
Output noise floor:
|
Analog input terminated with RCA Shorting Caps, unloaded: < 3 μV from 20 Hz to 20 kHz
|
|
Gain:
|
35dB
|
|
Dynamic range:
|
22 kHz measurement bandwidth (flat), true RMS unloaded: 110 dB
|
|
Damping factor:
|
380 at 1 KHz / 8 Ω
|
|
DIMENSIONS
|
330 W x 470 D x 270 H (mm)
|
|
WEIGHT
|
Weight: 65 kg
|
