SAFETY FEATURES

AC voltage fuse: 16 A slow-blow

Over-heating: the amplifier stops when heat sink temperature exceeds 80°C

Overload: Amplifier stops when output current exceeds 25A peak

HF protection: Amplifier stops when oscillations are detected on output

DC protection: Amplifier stops when continuous signal (DC) is higher than 5Vdc on output

FRONT PANEL CONTROLS

1 control key (ON/OFF)

Red led display for over-heating, DC offset or HF protection and overload

Green led display for Power ON, operating mode

Orange led display for signal connection and digital lock (blinking in standby)

REAR PANEL CONNECTORS AND CONTROLS

Universal socket 3 lugs with main fuse (16 A slow-blow)

USB Connector will provides access for future optional DSP board

Output speaker 1 x 5 ways post in parallel

Output speaker 1 x Coaxial connectors in parallel

Analog Input connector RCA

Digital Spdif input and output RCA connector (Alize 6 D/A converter)

Switch between analog or digital input

Switch right or left channel selection from the Spdif input

POWER

Maximum power (IEC60065): 300 Wrms on 8 Ù / 1%THD

Rated power consumption (IEC 60065 at 8 Ù): 180 W.

Maximum power consumption: 490 W.

Nominal line voltage: 117, 234 V (selectable internally)

Input voltage range: +/- 10 %

4 toroidal transformers

BANDWIDTH

+/- 0.1 dB, 0 - 300 kHz

+/- 1 dB, 0 - 1000 kHz

+/- 3 dB, 0 - 3 MHz

DISTORTION

Static: THD < 0.05 % (test conditions: Vin = 1kHz @ 100mV, unweighted)

SPEED

Rise time: < 300 ns

OPERATING TEMPERATURE

Room temperature: -30 to +40 degrees Celsius (-22 to +104 degrees Fahrenheit)

Internal temperature: +45 to +65 degrees Celsius (+113 to +149 degrees Fahrenheit)

POWER SUPPLY

Ultra fast power supply with 4 separate transformers and low impedance filtering capacitors.

MECHANICAL CONSTRUCTION & GROUNDING

Mechanical grounding optimum construction

Thermal grounding full implementation with gold-plated copper buffer plate

DIMENSIONS & WEIGHT

Dimensions: 305 W x 385 D x 230 H mm

Weight: 30Kg
