POWER RATING:

Nominal Line Voltage 117 ; 234V

AC line range: 10%

Fuse 8A for 115 and 230V

2 toroidal transformers

Separated ground and earth signal

Connection between earth and ground to cancel all ground loops

OUTPUT POWER:

Power RMS (Goldmund FPP Standard): 320Wrms on 8 Ω.

Maximum power (IEC60065): 2 x 215 Wrms on 8 Ω / 1%THD

Rated Power Consumption (IEC60065): 300 W

DISTORTION: With 20 Vrms output level

MD < 0,04%

BANDWIDTH:

20Hz – 20KHz: +/-0,2dB on 8 Ω.

+/- 3dB: 0Hz - >200KHz on 8 Ω.

SLEW RATE:

8V/μS

AMPLIFIER GAIN:

35dB

INPUT:

Maximum input sensitivity: 1Vrms

NO-CLIPPED OUTPUT VOLTAGE:

Maximum voltage: 153Vpp

DAMPING FACTOR:

173

                SAFETY FEATURES:

Automatic switching to MUTING if the AC line drops or is interrupted.

FRONT PANEL:

ON/OFF Switch

Green LED for power

REAR PANEL:

Power cord socket 3 lugs

Voltage selctor 115/230V

1 pair of RCA connector (left and right)

2 pairs of output speakers connector (left and right)

DIMENSIONS AND WEIGHT:

Dimensions: 440 W x 405 D x 130 H (mm)

Weight: 15 Kg
