POWER SUPPLY
|
Nominal line voltage:117 or 234 V (switchable)
|
|
Fuse 8A for 110V and 220V
|
|
Input voltage range:+/- 10 %
|
|
POWER
|
Nominal power:2 X 210W on 8 Ohms before clipping
|
|
Maximum voltage:55V peak These values are for both driven channels.
|
|
ANALOG INPUTS
|
4 x RCA analog input (Left & Right)
|
|
DIGITAL INPUTS
|
1 x Digital S/PDIF coaxial RCA 75 Ohms or Toslink Optical
|
|
1 x Digital S/PDIF coaxial RCA 75
|
|
1 x USB AUDIO
|
|
REAR PANEL CONNECTORS AND CONTROLS
|
2 x output binding posts Left & Right
|
|
1 x USB Audio connector
|
|
ON/OFF power switch key
|
|
Voltage input selector
|
|
RS232 Command connector
|
|
FREQUENCYRESPONSE
|
+/- 0.5 dB, 20 - 20 kHz
|
|
Typical phase error between channels:< 0.5 degrees
|
|
DISTORTION Measured with 20 Hz - 20kHz bandwidth and 80 kHz signal:
|
Static:THD + N ratio <0.002%
|
|
NOISE
|
Signal-to noise ratio:> 120 dB at 0 dBFS
|
|
OPERATING TEMPERATURE
|
Room temperature:-30 to +40 degrees Celsius (-22 to +104 degrees Fahrenheit)
|
|
Internal temperature:+45 to +65 degrees Celsius (+113 to +149 degrees Fahrenheit)
|
|
DIMENSIONS AND WEIGHT
|
44 W x 43 D x 13 H (cm)
|
|
Weight:15 kg
|
