COMPATIBILITY
|
BD-VIDEO, Blu-Ray 3D , DVD-Video, DVD-Audio, AVCHD, SACD, CD,
|
|
HDCD, Kodak Picture CD, CD-R/RW, DVD±R/RW, DVD±R DL, BD-R/RE
|
|
BD PROFILE:
|
BD-ROM Version 2.5 Profile 5 (also compatible with Profile 1 Version 1.0 and 1.1)
|
|
INTERNAL STORAGE
|
1GB (Actual space available for persistent storage varies due to system usage)
|
|
OUTPUT
|
Analog Audio: 7.1ch or 5.1ch, stereo
|
|
Digital Audio: Coaxial, Optical up to 2ch/192kHz PCM, Dolby Digital, DTS.
|
|
HDMI Audio: Stereo, up to 7.1ch/192kHz PCM, up to 5.1ch DSD, Dolby Digital, Dolby Digital Plus,
|
|
Dolby TrueHD, DTS, DTS-HD High Resolution, DTS-HD Master Audio.
|
|
HDMI Video:480i/480p/576i/576p/720p/1080i/1080p/1080p24/4Kx2K, 3D frame-packing 720p/1080p24.
|
|
EXTERNAL CONNECTION
|
External IR Remote Control
|
|
RS232 Control
|
|
INPUT
|
HDMI Audio: up to 5.1ch/192kHz or 7.1ch/96kHz PCM, Dolby Digital, Dolby Digital Plus, DTS,
|
|
AAC.
|
|
HDMI Video: 480i/480p/576i/576p/720p/1080i/1080p/1080p24/1080p25/1080p30, 3D frame-packing 720p/1080p24.
|
|
MHL Audio: up to 5.1ch/192kHz PCM, Dolby Digital, Dolby Digital Plus, DTS.
|
|
MHL Video: 480i/480p/576i/576p/720p/1080i/1080p24/1080p25/1080p30, 3D frame-packing 720p/1080p24.
|
|
AUDIO CHARACTERISTICS
|
Frequency: 20Hz – 20kHz (±0.05dB), 20Hz – 96kHz (-4.5dB ~ +0.05dB)
|
|
Signal-to-Noise Ratio: >115dB (A-weighted)
|
|
THD+N: < 0.006% (1kHz at 0dBFS, 20kHz LPF)
|
|
POWER
|
Power Supply: ~ 100V – 240V, 50/60Hz AC
|
|
Power Consumption: 35W (0.5W in Energy Efficient Mode)
|
|
DIMENSIONS AND WEIGHT
|
440 W x 130 H x 370 D (mm). 12 kg.
|
