Amplifier section
|
|
Clipping point of the preamplifier is set to a level where total harmonic distortion (THD) is 0.2%
|
|
Input Impedance (Fixed)
|
330 kohm
|
|
Output Impedance (20 Hz-20kHz)
|
< 0,009 Ohm
|
|
Frequency response (DC - 65 kHz)
|
- 0.4 dB
|
|
Input level for rated output
|
1 V RMS
|
|
Max. peak current
|
> 150 A
|
|
THD(measured at 1 kHzhalf power,8W)
|
< 0,001 %
|
|
THD (measured at 1 kHz -1 dB, 8 W)
|
< 0,0015 %
|
|
Noise
(measured with bothinputsshorted)
|
400 Hz - 30 kHz : 150 µV
DC - 30 kHz : 200 µV
|
|
Damping factor (20 Hz - 20 kHz)
|
> 850
|
|
Rated output power
|
|
8 ohms
|
600 W
|
|
4 ohms
|
1200 W
|
|
Power consumption (no load or signal)
|
230 W
|
|
The NEMO is DC coupled from input to output
|
|
|
Dimensions
|
|
Width
|
465 mm / 18.3 inches
|
|
Depth
|
450 mm / 17.7 inches
|
|
Height
|
288 mm / 11.3 inches
|
|
Weight
|
41 kg. / 90.2 lbs.
|
