Amplifier section
|
|
Output Impedance (20 Hz - 20 kHz)
|
< 0,008 ohm
|
|
XLR (balanced) input impedance
|
110 kohm
|
|
Input sensitivity for rated output
|
1 V
|
|
Max. peak current
|
> 100 A
|
|
THD (measured at 1 kHz half power, 8 W)
|
< 0,001 %
|
|
THD (measured at 1 kHz -1 dB, 8 W)
|
< 0,001 %
|
|
Noise (measured with both inputs shorted)
|
400 Hz - 30 kHz : 90 µV
10 Hz - 30 kHz : 100 µV
|
|
Output Impedance (20 Hz - 20 kHz)
|
< 0,008 ohm
|
|
Rated output power
|
|
8 ohms
|
2 x 250 W
|
|
4 ohms
|
2 x 380 W
|
|
2 ohms
|
2 x 625 W
|
|
1 ohms
|
2 x 1100 W
|
|
Power consumption (no load or signal)
|
230 W
|
|
Dimensions
|
|
Width
|
483 mm / 19 inches
|
|
Depth
|
450 mm / 17 inches
|
|
Height
|
210 mm / 8.2 inches
|
|
Weight
|
39 kg. / 85.8 lbs.
|
