SPECIFICTIONS

Output Impedance
(20 Hz - 20 kHz)

< 0,008 ohm

RCA (single) input impedance

220 kohm

XLR (balanced) input impedance

110 kohm

Input sensivity for rated output

1 V

Max. peak current

> 100 A

THD (measured at 1 kHz half power, 8 W)

< 0,001 %

THD (measured at 1 kHz -1 dB, 8 W)

< 0,001 %

Noise (measured with both inputs shorted)

400 Hz - 30 kHz : 90 µV
10 Hz - 30 kHz : 100 µV

Rated output power

8 ohms

250 W

4 ohms

380 W

2 ohms

625 W

Power consumption (no load or signal)

115 W

Dimensions

Width

215 mm / 8.5 inches

Depth

470 mm / 18.5 inches

Height

288 mm / 11.3 inches

Weight

22 kg. / 48.4 lbs.
