All measurements are made at 120V / 240V //50Hz / 60Hz
|
|
Input impedance balanced (fixed)
|
47 Kohm
|
|
Output impedance
|
100 ohm
|
|
Input level (Single ended)
|
>15 Vp-p
|
|
Input level (balanced)
|
>30 Vp-p
|
|
Max output level (Single ended)
|
>15 Vp-p
|
|
Max output level (Balanced)
|
30 Vp-p
|
|
Gain
|
- 111dB to +6dB
|
|
Noice Floor
|
<-130dB (@ 0dB gain)
|
|
Frequency responce
|
0.5 - 200.000 Hz
|
|
Channel Seperation
|
> 120dB
|
|
THD + N
|
<0.002%
|
|
IMD
|
TBD
|
|
Power consumption (no load or signal)
|
30 W
|
|
Dimensions and Waight
|
|
Width
|
483 mm / 19 inch
|
|
Depth
|
386 mm / 16.1 inch
|
|
Height
|
76 mm / 4.5 inch
|
|
Weight
|
9 kg
|
|
Inputs
|
|
Balanced
|
2 x2 channel
|
|
Single ended
|
3 x 2 channel
|
|
Control Ports
|
|
Nettwork
|
3 x SPAC
|
|
Programming
|
1 x USB
|
|
Outputs
|
|
Balanced
|
1 x 2 channel
|
|
Single ended
|
Record Out
|
