Line section

Single ended gain

1.6X (4dB)

Balanced gain

3.2X (10dB)

THD (1V out, 1KHz)

< 0,002%

Maximum output (Balanced)

> 14V RMS

Channel separation (1V out, 1KHz)

> 90 dB

Equivalent input noise

4µV

Digital section

Latest version of Phillips CD PRO Top loading drive unit

24 Bit upsampler 192KHz DAC

Digital out RCA/XLR

Other

True balanced system

Mechanical filter which cancels acoustic/mechanical vibrations preventing the laser pick-up

from receiving unwanted signals

FTT Power supply

Fully remote (no volume control)

Power consumption (no load or signal)

23 W

Dimensions

Width

483 mm / 19 inches

Depth

440 mm / 17.3 inches

Height

115mm / 4.5 inches

Weight

20Kg / 44 lbs.
