Technical Data
Conditions
No. of channels
2
Video
No
Output impedance
100 ohm
Output level
Unbalanced
2.3Vrms
Balanced
4.6Vrms
Noise floor
20 - 20 kHz
< - 130 dB
Frequency deviation
< 0.05 dB
Channel separation
> 110 dB
THD + N
< 0.002%
IMD
TBD
Digital/Analog Conversion
24 bit, 192 kHz
Dynamic Range
120 dB
Compatible formats
CD-R, CD-RW, MP3-CD, CD, MP3-DVD, WMA-CD
Dimensions
W x D x H
483 x 385 x 105 mm
Weight
9 kg
Power consumption
No load or signal
35 W
Audio Outputs
1 x 2 ch balanced line out (XLR) 1 x 2 ch unbalanced phono
Digital Outputs
75 ohm S/PDIF RCA
