SPECIFICATIONS
|
|
Rated Power into 8 ohm / 4 ohm (IHF)
|
150W / 240W
|
|
Rated THD and IMD
|
<0.03%
|
|
1 KHz Clipping Power into 8 ohm / 4 ohm
|
160W / 230W
|
|
Dynamic Power into 8 ohm / 4 ohm
|
255W / 360W
|
|
Dynamic Headroom
|
1.7dB
|
|
Current limit @ .1 ohm and 1 ohm
|
30 Amps
|
|
Output offset
|
+/-10mV Max
|
|
S/N Ratio for 1W/8 0hm
|
>102dB ("A" wtd)
|
|
Input voltage for 100 watts
|
1 Vrms
|
|
Frequency Response
|
|
20Hz-20KHz
|
+/-.3dB
|
|
-3dB
|
4Hz&75KHz
|
|
Separation
|
>70dB @ 20KHz
|
|
Damping Factor
|
>200
|
|
Input Impedance
|
22K/150pf
|
|
DIMENSIONS (W x D x H)
|
|
2N100MKII, 2N100-2 & 2N100-3
|
17in x13in x 5in
|
|
2N100-5
|
17in x 14in x 7in
|
|
WEIGHT
|
|
2N100MKII & 2N100-2
|
27 Lbs.
|
|
2N100-3
|
34 Lbs.
|
|
2N100-5
|
37 Lbs.
|
