Designer:
|
Jonathan Carr
|
|
B uilder:
|
Yoshinori Mishima
|
|
T ype:
|
Medium weight, medium compliance, low-impedance moving coil cartridge
|
|
Stylus:
|
Lyra-designed long-footprint variable-radius line-contact nude diamond (3um?70um profile, block dimensions 0.08 x 0.12 x 0.5mm), slot-mounted
|
|
Cantilever system:
|
Diamond-coated solid boron rod with short one-point wire suspension, directly mounted into cartridge body via high-pressure knife-edge system
|
|
Coils:
|
2-layer deep, 6 N high-purity copper, chemically-purified high purity iron X-shaped former, 4.2 ohm self impedance, 11uH inductance
|
|
Output voltage:
|
0.56 mV@5 cm/sec., zero to peak, 45 degrees (CBS test record, other test records may alter results)
|
|
Frequency range:
|
10 Hz-50 kHz
|
|
Channel separation:
|
35 dB or better at 1 kHz
|
|
Compliance:
|
Approx. 12 X10 cm/dyne at 100 Hz
|
|
Vertical tracking angle:
|
20 degrees
|
|
Cartridge body:
|
Multi-material (titanium, duralumin, bronze, stainless steel) self-clamping construction with reduced-surface higher-pressure headshell contact area, predominately non-parallel shaping, phase-interference resonance-controlling mechanisms, body threaded for mounting screws
|
|
Cartridge mounting screws:
|
2.6 mm 0.45 pitch JIS standard Cartridge weight (without stylus cover): 9.2g
|
|
Distance from mounting holes to stylus tip:
|
9.52mm
|
|
Recommended tracking force:
|
1.68-1.78g (1.72 g recommended)
|
|
Recommended load directly into MC phono input:
|
104 ohm-887ohm (determine by listening, or follow detailed guidelines in owner's manual)
|
|
Recommended load via step-up transformer:
|
5-15 ohm (connect step-up transformer's output to 10kohm-47kohm MM-level RIAA input, preferably via short, low-capacitance cable)
|
|
Recommended tonearm:
|
High-quality pivoted or linear (tangential) tonearm with rigid bearing(s), adjustable anti-skating force, preferably VTA adjustment
|
