Digital section
|
|
D/A converter
|
24 bit/192 kHz
|
|
Sample rate converter
|
24bit / 192kHz
|
|
Inputs
|
SPDIF, 2x Toslink, 1x USB
|
|
USB:
|
asynchronous up to 24bit/ 192kHz supported
|
|
SPDIF:
|
24bit/ 192kHz
|
|
Toslink:
|
24bit/ 96kHz
|
|
Wi-Fi / LAN transfer:
|
24bit/ 192kHz
|
|
Wi-Fi:
|
b/g/n, SGA- connector for external antenna
|
|
LAN:
|
10 / 100MBit/s DHCP and Auto IP support
|
|
Supported standards:
|
DLNA, UPnP, vTuner.
|
|
Supported audio formats:
|
MP3 up to 320kBit/s, WAV, AIFF, PCM up to 24bit/192kHz, FLAC 24bit/192kHz, OGGVorbis, WMA standard, AAC / M4A
|
|
Preamplifier section
|
|
Input impedance (Balanced input )
|
47Kohm
|
|
Maximum input level
|
10 Volt RMS
|
|
Noise floor ( 1Vrms, 20 - 20 kHz, balanced)
|
-135 dB
|
|
THD + N (1Vrms, 20 - 20 kHz, balanced)
|
<0.004%
|
|
Gain (Balanced)
|
0 dB
|
|
Amplifier section
|
|
Output Impedance
|
< 0,02 Ohm
|
|
Frequency response
|
1 – 150 kHz
|
|
Channel separation
|
> 120 dB
|
|
THD ( 20 - 20 kHz)
|
< 0.004%
|
|
Maximum peak current
|
>100A
|
|
Damping factor 8 ohm load
|
>350
|
|
I Input sensitivity 120W output
|
1.3Vrms
|
|
Input sensitivity HT 120W output
|
1Vrms
|
|
Gain HT Input
|
x36 (31 dB)
|
|
Rated output power
|
|
8 ohms
|
2 x 125 W
|
|
4 ohms
|
2 x 200 W
|
|
2 ohms
|
2 x 370 W
|
|
Power consumption
|
110 W
|
|
Standby
|
1W
|
|
(no load or signal)
|
|
|
Dimensions
|
|
Width
|
465 mm / 18.3 inches
|
|
Depth
|
405 mm / 16 inches
|
|
Height
|
128 mm / 5 inches
|
|
Weight
|
20Kg / 44 lbs.
|
