SPECIFICTIONS

Type

low output moving coil cartridge with flux damper and alnico magnet

Output Voltage

 0.26mV (at 1KHz, 5cm/sec.)

Channel Separation

 30 dB (at 1KHz)

Channel balance

 1.0 dB (at 1KHz)

Frequency response

 20 - 20,000Hz (± 1dB)

Compliance

 10 x 10^-6 cm/dyn

Tracking force

 1.8 - 2.2 grams

DC resistance

 R=5 ohms

Recommended load
impedance

 >30 ohms

Cantilever

 6mm length solid boron

Stylus

 PF Line contact shape, stylus radius: 7 x 30 micron

Weight

 9.8 grams
