SPECIFICTIONS
|
|
Type
|
Low output moving coil mono cartridge with multi Alnico magnets and the Flux damper
|
|
Output Voltage
|
0.25mV (at 1KHz, 5cm/sec. RMS horizontal)
|
|
Frequency response
|
20 - 50,000Hz
|
|
Compliance
|
6 x 10-6 cm/dyn (horizontal)
|
|
Tracking force
|
2.6 - 3.2 grams
|
|
Impedance
|
R=7 ohms
|
|
Recommended load
resistance
|
> 30 ohms
|
|
Cantilever
|
6mm length 0.3 mm dia. solid boron
|
|
Stylus
|
PF Line contact shape, stylus radius: 7 x 30 micron
|
|
Weight
|
12.6 grams
|
