SPECIFICATIONS
|
|
Rated Power into 8/4 ohms
|
45/60W
|
|
Rated THD 20-20KHz
|
0.05%
|
|
1kHz clipping power into 8/4 ohms
|
48/65W
|
|
Input sensitivity for 1W/Rated Power
|
High level inputs: 23mV/150mV
Phono Input MM: 0.5mV/2.7mV
Phono Input MC: 0.05mV/0.27mV
|
|
Input impedance
|
High level inputs: 20K ohms
Phono input MM/MC: 47K ohms/100pF
|
|
Frequency response
|
Tone bypass 20-20KHz: +/-0.5dB
Normal 20-20KHz: +/-1.0dB
High level inputs -3dB: 10Hz/60KHz
|
|
Signal to noise ratio (ref. 1W/8 ohms)
|
High level inputs +W+WWTD: 88dB
Phono input +W+WWTD: 88dB
|
|
Separation 20-20KHz
|
>65dB
|
|
Tone control range
|
Bass at 100Hz: +/-10dB
Treble at 10KHz: -8/+11dB
|
|
Overall feedback
|
26/29dB
|
|
PHYSICAL PROPERTIES
|
|
Dimensions (W x H x D)
|
430 x 82 x 288 mm
|
|
Net Weight
|
6.8Kgs
|
|
Shipping Weight (4 Pieces)
|
30.9Kgs
|
